REAR WHEEL INSTALLATION
(2.) Chain tensioner nut (13mm)
1. Ensure power is switched o and the key removed.
2. Li the bike onto a block or stand so the wheels are o the ground.
3. Loosen the axle bolts (see image 1.)
4. Loosen the chain adjustment nuts to the point where the wheel can be pushed forward,
and the chain slipped o to the right of the sprockets (see image 2.)
5. Pull back on the wheel to remove it.
6. To re-install the wheel reverse the above procedures. Ensure the chain is correctly
adjusted and lubricated, the wheel is aligned, and all nuts and bolts are ght
(1.) Axle Nut (19mm)
