oset MX-10 Mk.1 - Removing the Seat

17
ADJUSTING THE FRAME HEIGHT
The frame of the MX-10 features an overall height adjustment. The procedure to change this
height is outlined below.
1. With the seat unit removed, undo & remove the bolt in the upper shock mount
(see image 1 below).
2. Push up on swing arm unl rear shock mounng hole aligns with desired mounng hole
on the frame.
3. Re-insert shock bolt & ghten nut (see image 2 below).
(1.) (2.)
The padded seat unit of your MX-10 bike is removable, allowing access to some of the bike’s
electrical components. By removing the two screws shown below, the seat can be lied up &
backwards to release from the bike.
(1.) Unscrew & remove seat bolts. (2.) Li seat up & backwards to release.
REMOVING THE SEAT
