Spare parts list CPTX 270 GB
47
CPTX 270/CPTX 330
Note: The parts under Pos. 8, 9, 12, 28, 46, and all external cables are wear parts and the
manufacturer resumes no guarantee!
* Subject to modifications
Figure
Pos.
Description
CPTX 270
1
01
Switch with lamp
0073-04-0001
1
03
Selector switch 1-10
0073-04-0004
1
04
Control lamp
0072-04-0003
1
05
Lable of the front panel
0406-04-0003
1
06
Button potentiometer
0403-04-0001
1
07
Main cable
0071-04-0010
1
08
Electrical socket
0071-04-0005
1
09
Wheel 200
0410-04-0003
1
10
Cover panel
0411-04-0002
1
11
Axis
0302-04-0002
1
12
Swivel wheel
0410-04-0004
2
20
Isolation transformer
0080-04-0003
2
21
Primary winding
0081-04-0001
2
22
Secondary winding
0081-04-0002
2
23
Transformer
0080-04-0004
2
25
Gas valve
0104-04-0001
2
26
Fence PVC
0310-04-0014
2
27
Chain
0412-04-0001
2
28
Handle
0405-04-0005
2
29
Reciftier
0076-04-0002
2
30
Upper front panel PVC 400-1
0310-04-0018
2
31
Front panel PVC 400-2
0310-04-0019
2
32
Front panel PVC 400-3
0310-04-0020
3
33
Connector 5-pole
0071-05-0007
3
34
Power cable
0050-04-0061
3
35
Cable discharge
0407-04-0001
3
37
Top cover
0310-04-0015
3
36
Side cap left
0310-04-0017
3
39
Side cap right
0310-04-0016
4
38
Side door
0310-04-0021
4
40
Catch
0320-04-0001
4
42
Nut bolt
0100-04-0002
4
43
Safety fuse
0075-04-0004
4
44
Feed motor
0082-04-0001
4
45
Feed mechanism
0030-04-0008
4
46
Wire feed roll 0,6 - 0,8
0430-04-0002
4
46
Wire feed roll 1,0-1,2
0430-04-0004
4
48
Contactor
0079-04-0002
4
49
Choke
0078-04-0001
