31
Place the Antenna Fixture on a table with the
bearing liner facing upwards. Peel o the rst
part of the bearing liner. Do not touch the
adhesive side as this will decrease its
adhesiveness.
Attach the Antenna Fixture on the skin on top
of the Implant by pressing the adhesive half of
the xture onto the bare skin. Orient the Antenna
Fixture so the large opening points upward.
Figure 7: The 3 layers of the Antenna Fixture
Bearing
Liner
Adhesive
Applicator
Liner
