59
14.8 ActiGait® Heel Sock
Sizes XS, S, M, L, XL, XXL
Washing directions
1. Maximum 40 °C normal machine wash
2. Do not bleach
3. Do not iron
4. Do not dry-clean
5. Do not tumble-dry
14.9 ActiGait® Charger Cable
Dimensions 3.5 cm x 4.7 cm x 1.8 cm
Mass 33 g
Input voltage 5 VDC
Input current 500 mA
Frequency DC
Output voltage 5 VDC
Output current Max 500 mA
Ingress IP 4X
Operating temperature Between +10 °C and +40 ºC
Storage temperature Between +10 °C and +40 °C
Humidity 30 – 75 % rel. H non-condensing
Short time storage and
transportation tempera-
ture
Between -20 °C and +60 °C for max 2 months
