60
14.10 ActiGait® Charger
Mass 50 g
Input voltage 100-240 VAC (±10 %)
Output voltage 5 VDC
Input current 75 mA
Output current Max 500 mA
Frequency input 50-60 Hz
Eciency 70 % typ. at full load
EMC
Conforms to EN 55022 + A1, CISPR 16-1, CISPR
16-2, AS/NZS CISPR 22
Output voltage tolerance ± 5 %
Operating temperature Between 10 °C and +40 ºC
Storage temperature Between 10 °C and +40 °C
Humidity 5 % to 95 % non-condensing
Short time storage and
transportation tempera-
ture
Between -20 °C and +60 °C for max 2 months
Standards
Fulls Class II SELV for the following applica-
tions: EN 60950/IEC 60950, UL 60950, VDE, CE
label
Plug connector
AC input: FRIWO exchangeable mains plug sys-
tem: EURO, UK, USA/Japan, Australia
DC output: USB socket type A
