64
Flip up the footplate.
Grasp the middle of the seat upholstery in the front and the back and pull up. The wheelchair
will fold (Fig. 3).
Use the safety strap to hold the folded wheelchair in position when it is being lifted (Fig. 4).
3
4
During reassembly, ensure that the footrest locking device has engaged.
Depending on the wheelchair model, further options are available for making the wheelchair more
manageable for car transport etc. With the model »Avantgarde T« with single-panel footrest you
can swing away the left part of the footrest with footplate to the outside to reduce the folding
with (Fig. 5). The Avantgarde VR and XXL 2 models allow you to swing away and detach the
footrests, thus reducing the overall length of the wheelchair.
5
6
Transportation is greatly facilitated by the removable quick-release axles on the rear wheels
(included in the standard version) (Fig. 6).
