76
5.11 Rear Wheels (Fig. 47/48)
Spox wheels (Fig. 47) and Innity Ultralight wheels (Fig. 48) can be selected among others.
47
48
5.12 Brake/Wheel Lock Systems /Wheel Lock Accessories (Fig. 49/50)
(not illustrated)
Allows the attendant to comfortably and safely brake the wheelchair. The rear wheels remain
removable via the quick-release axle system.
(Fig. 49)
Can be swung to the inside of the frame. Makes transfer from the wheelchair easier and, in
combination with transport wheels, reduces the overall width of the wheelchair.
49
(Fig. 50)
Recommended especially for hemiplegics. It can be activated either on the right or left side and
ensures the safe locking of both rear wheels with a pull-wire system.
Please note that the folding wheel lock lever extension must always be attached when
releasing or engaging the wheel lock.
