67

The wheelchair is designed as a modular component system. This means that certain acces-
sories can be adapted to your wheelchair. In the following, we will present you a selection of our
variants and accessories which improve the use and comfort of your wheelchair.
We recommend using a seat cushion at all times. The seat upholstery of the Avantgarde wheel-
chair has a loop texture so that seat cushions can be attached with hook and loop connection.
All seat cushions listed on the order form have the required hook texture.
5.1 Anti-tipper (Fig. 15)
Prevents the wheelchair from tipping too far backward. The anti-tipper is strongly recommended
for untrained wheelchair users and children, as well as when extreme adjustments have been
made to the rear wheel. With slight downward pressure on the anti-tipper, it can be disengaged
and swung to the inside (refer to section ”Adjustments /Assembly Instructions”).
(Fig. 16)
Makes it easier for an attendant to tip up the wheelchair, e.g. to cross a step. The tip-assist must
be mounted so that the distance to the ground is at least 4 cm.
1615
max.
5 cm
min.
4 cm
5.3 Crutch Holder with Hook and Loop Strap (Fig. 17)
Allows crutches to be attached to the wheelchair.
