Page 20
Service Instructions B500
Settings/substitution/replacement
Replacing or removing a seat frame
Removal:
- Undo two screws on every side of the back
part, and remove the bake part
- Remove the seat section and the lateral
element retainers
- Remove all cables which are fastened to the
seat frame by cable binders
Do not damage the cables!
- Undo the seat lug screws, and remove the
seat frame
Installation:
- Position the seat frame, and tighten the seat
lug screws
- Reinstall all cable connections
- Mount seat section and lateral element
retainers
- Position the back part, and secure it using
two screws on every side of the back part
Please also refer to the section on the standard seat when working on this section.
