Page 34
Service Instructions B500
Settings/substitution/replacement
4.4.1.14 Accessories
Joystick accessories
Withdraw the top joystick end to fasten the joy-
stick accessories. Accessories like tetra fork, golf
ball, stick, etc. may be put on the metal pin.
Stick holder
The stick holder of the B500 is fastened to the
lateral element at the bottom of the arm cushion.
The arm cushion has two boreholes (see arrows)
which are used to screw on the stick holder.
