Service Instructions B500
Maintenance schedule and tools needed
Maintenance schedule
for yearly inspection
B500
Component
o ElectronicsControl unit
o Fluid level
o Battery box
o Cabling
o Suspension
o Drive support
o Motor
o Rockers
o Brake release
o Tilting protection
o Cabling
1
6
7
5
4
3
2
8
9
10
11
12
13
Lateral elements
Control unit accessories
Accessories
Foot notch
Seat system options
Recaro seat system
Standard seat
Drive wheels
Front wheels
Lighting
Frame
Battery
Item
o Light holders
o Lamp housing
o Lamps
o Cabling
o Handlebar fork
o Suspension
o Handlebar lock
o Edge mounting aid
o Tires
Function
Damage/
Deformation
Screw
connections
o Covering
o Seat & back frame
o Seat section
o Lateral element retainer
o Seat lugs
o Tires
o Seat lock
o Subframe
o Seat modules
o Seat lugs
o Seat shell retainer
o Abduction wedge
o Head rests
o Foot notch socket
o Foot board
o Foot notch support
o Control unit holder
o Joystick
o Treatment table
o Arm rests
o Arm supports
Check
(Check the box when the item is OK)
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
Servicing performed by: dated:
