Page 24
Service Instructions B500
Settings/substitution/replacement
Readjusting the seat height
The procedure to adjust the seat height for Recaro
seats is similar to the procedure used for standard
seats.
- Remove the seat (see previous section)
- Replace the seat lugs
Replacing seat modules
The seat surfaces of Recaro seat modules use the
same fastening to the seat frame as the complete
Recaro seats, and they are dismounted using the
same procedure.
The modular seat backs are hooked to the seat
surfaces. Two retainers are located at the seat
surfaces.
Perform the following work steps:
- Install a locking plate at the front retainer
- Hook the back rest to the seating surface
- Fasten the front locking device to the rear
retainer
