OutBack Power Systems Inc.
PREPARING FOR RECHARGING
Turn the PV input breaker on. The MX60
automatically detects the PV input voltage.
(Note: If PV voltage registers “000V” when the breaker
is on, please check the polarity of the PV wires.)
After 5 seconds of stable input voltage, the MX60
enters a “Wakeup” stage, transitions to “Sweeping”
and prepares to charge the batteries by tracking the
MPP of the solar array.
PV 113 V Bat 12.5 V
00.0 A 00.0 A
Watts 0000 Aux Off
kWHrs 00.0 Sleeping
PV 087 V Bat 12.5 V
05.0 A 32.9 A
Watts 0412 Aux Off
kWHrs 00.0 B-MPPT
