Parts List
Quantity varies according to model purchased. Specifications subject to change without prior notice. For
more details on hardware, please see the corresponding ‘Hardware Reference Diagram’.
Pre-Assembled Component
Quantity varies according to model purchased
Appearance, size, and construction may differ according to model purchased
CODE PART QTY
Outback® Half Drum
Charcoal BBQ
BODY
B1 Barbecue Body 1
B2 Upper Bracket 1
B3 Trolley Handle 1
B4 Tool Hook 3
B5 Side Shelf 1
B6 Side Shelf Bracket 2
B7 Left Wind Shield 1
B8 Right Wind Shield 1
B9 Rear Wind Shield 1
B10 Charcoal Grill 2
B11 Cooking Grill Lower Support 1
B12 Cooking Grill 2
B13 Cooking Grill Upper Support 1
B14 Grill Lifting Handle 2
TROLLEY
C1 Left Front Leg 1
C2 Left Rear Leg 1
C3 Right Front Leg 1
C4 Right Rear Leg 1
C5 Screen 1
C6 Trolley Base 1
C7 Axle Spacer 2
C8 Locknut 2
C9 Axle 1
C10 Wheel 2
C11 Wheel Hubcap 2
HARDWARE
D1 M6x15 Bolt 22
D2 M6x35 Bolt 14
D3 M6 Nut 24
D4 R Shape Clip 4
D5 Side Shelf Pin 4
D6
ST4.0x10 Screw
6
