Carefully place the barbecue body assembly onto the trolley assembly and fix using
M6x35 Bolts (D2x4pcs) and M6 Nuts (D3x4pcs) as shown.
Attach the Trolley Handle (B3) onto the Barbecue Body (B1) using the M6x15 Bolts (D1x2pcs).
D2
D3
D1
B3
B1
