Outback CD100 - Assembly Steps 9 & 10

9
9
10
Attach the Rear Wind Shield (B9) onto the barbecue body using the
M6x15 Bolts (D1x2pcs) .
NOTE: Only fixed both ends.
Attach the Cooking Grill Lower Support (B11) onto the barbecue body
using the M6x15 Bolts (D1x4pcs) .
Note: Ensure that Long end of the cooking grill lower support at
the front of the barbecue.
L
o
n
g
S
h
o
r
t
B9
B11
