Outback Excel 310 - Page 14

14
20
19
C6
D1
Attach the Side Burner Shelf (C6) to the left front and left rear legs using M6x15 Bolts
(D1x4pcs).
Remove the screws from Side Burner Valve / Hose Assembly (C9) and secure it to the
side shelf with those 2 screws.
Assemble the Side Burner Knob (C4) onto the side burner valve.
C4
C9
