Figure 24 - Max Absorb Time
Max Absorb Time: (Maximum Absorb Time in hours)
Sets the maximum amount of time the MX60 is allowed to stay in the Absorb
charge stage. Adjustable from 1 to 4 hours.
18
Figure 25 - AUX POLARITY
OPTIMIZATION
Aux Polarity
Active High
EXIT NEXT MODE
Aux Polarity: Selects whether the Auxilliary Output is “Active High” (12 Volts applied
to terminals when the Aux function’s condition is True), or ”Active Low”, (no voltage is
applied to the terminals when the function’s condition is true.) Either way, a display of
“On” means that 12 Volts is applied to the Aux Output terminals.
