Owon B41T User Manual

2.Quick Start
11
Input terminals
The terminal connections for the different measurement functions of the multimeter are
described in the table below.
Warning:
Before starting any measurement,
observe the rotary switch
position of the multimeter, and then
connect the test leads to the
correct terminals.
C
aution: To avoid damaging the multimeter, do not exceed the rated input limit.
Input terminals on 35 series multimeter
Rotary switch position
Input terminals
Overload protection
750 VAC/1000 VDC
250 VDC or
Equivalent voltage RMS
250 VAC or
Equivalent voltage RMS
1 A/250 V, fast-acting fuse
20 A/250 V, fast-acting fuse
Input terminals on B41T(+)
Rotary switch position
Input terminals
Overload protection
750 VAC/1000 VDC
250 VDC or
Equivalent voltage RMS
