Owon VDS Series Quick Guide

1
VDS Series PC Oscilloscopes Technical Specifications
Note: "I" indicates the model has the power supply isolation and earth ground isolation
between the oscilloscope and PC (optional), the two channels are non-isolated electrically.
"L" indicates LAN port (optional).
Model Bandwidth Sample rate Rise time Horizontal Scale(S/div)
VDS1022(I)
25 MHz 100 MS/s  ns 5ns/div - 100s/div, step by1-2-5
VDS2062(L)
60 MHz 1 GS/s  ns 5ns/div - 100s/div, step by1-2-5
VDS3102(L)
100 MHz 1 GS/s  ns 2ns/div - 100s/div, step by1-2-5
VDS2064(L)
60 MHz
1GS/s for 1CH
500MS/s for 2CH
250MS/s for 4CH
 ns 5ns/div - 100s/div, step by1-2-5
VDS3104(L)
100 MHz 1 GS/s  ns 2ns/div - 100s/div, step by1-2-5
Sampling mode
Sample, Peak detect, Average
Channel
VDS1022(I)
VDS2062(L)
VDS3102(L)
2 + 1 (MULTI port)
VDS2064(L)
VDS3104(L)
4 + 1 (MULTI port)
Max Record length
VDS1022(I) 5 k
VDS2062(L)
VDS3102(L)
10 M
VDS2064(L)
VDS3104(L)
5 M
Input coupling
DC, AC , Ground
Input impedance
1 0ȍ ± 2%, in parallel with 15 pF ± 5 pF
Max. input voltage
VDS1022I 400 V (DC + AC Peak)
VDS1022
40 V (DC + AC Peak)
VDS2062(L)
VDS2064(L)
VDS3102(L)
VDS3104(L)
DC gain accuracy
±3%
Vertical sensitivity
VDS1022(I)
5 mV/div – 5 V/div
VDS2062(L)
VDS2064(L)
VDS3102(L)
2 mV/div – 5 V/div
VDS3104(L)
