Owon VDS Series Quick Guide

2
Trigger type
Edge, Video, Slope, Pulse, Alternate
Trigger mode
Auto, Normal, Single
Line/field
frequency (Video)
Support standard NTSC, PAL and SECAM broadcast systems
Automatic
measurement
Vpp, Vmax, Vmin, Vtop, Vbase, Vamp, Vavg, Vrms, Overshoot, Preshoot,
)UHT3HULRG5LVH7LPH)DOO7LPH'HOD\$ĺ%
'HOD\$ĺ% , +Width,
-Width, +Duty, -Duty
Waveform Math
ˇ, ˉ, ×, ÷, FFT
Communication
interface
VDS1022(I) USB 2.0 Full Speed
VDS2062(L)
VDS3102(L)
VDS2064(L)
VDS3104(L)
USB 2.0 High Speed, LAN (optional)
Power supply
VDS1022(I) 5.0 V/500 mA Power consumption < 2.5 W
VDS2062(L)
VDS3102(L)
VDS2064
VDS3104
5.0 V/1 A Power consumption < 5 W
VDS2064L
VDS3104L
5.0 V/1.5 A Power consumption < 6.5 W
Dimension
VDS1022(I) 170 mm × 120 mm × 18 mm (L*H*W)
VDS2062(L)
VDS3102(L)
VDS2064(L)
VDS3104(L)
190 mm × 120 mm × 18 mm (L*H*W)
Weight
About 0.26 kg
V1.1
