Serial 1 Output tab
The serial port can be configured to output different types of message (see Table 22).
Select a Packet type and Baud rate. By default, data on the serial port is output using 8-
N-1, although odd/even parity and two stop bits are available by using Advanced
commands. Please contact support@oxts.com for details on this.
If the NMEA packet type is selected, the NMEA tab will appear in the properties window.
In this tab the NMEA messages to output on the serial port are selected by choosing the
data rate for each message type from the dropdown lists and clicking the checkbox for
when to generate the message.
NMEA messages can also be generated in response to event input triggers. Check the
falling or rising edge checkbox to compute the message when the event occurs. The RT
can also generate NMEA messages from pulses on the output trigger. These messages use
interpolation to compute the values at the exact time of the event but may be output on
the serial port up to 30 ms late and out of order compared to the normal messages. To
enable these messages check the appropriate checkbox.
