R6000S Operation Manual: Rev. G
PAC L.P., All Rights Reserved, 2015 Page 39 of 92
Figure 5. Ground and Ground Wires
2.2.4 Pyrotube Installation
Perform the following steps to install the pyrotube.
1. Turn OFF power to the furnace and let it cool to a safe temperature.
DEATH OR SERIOUS INJURY COULD OCCUR IF NOT AVOIDED.
An electrocution hazard exists because severe electrical shock hazards exist
when working around the high-voltage and/or 115/230 VAC components while
power is applied.
HOW TO PROCEED: Avoid hazard by turning off the unit with the ON/OFF
switch and remove the power connection or power cord from the unit to the
power source. Also, follow any required lock-out/tag-out procedures your
company policy requires.
To prevent electrical shock hazard DO NOT operate this equipment in rain or
wet conditions.
