PEC017

5/3/2018 Page 34 of 105

Thresholds

Value

“Warning”

Reaction

“Derate”

Reaction

“Shutdown” Reaction

Aftertreatment

Shutdown

Request

DOC Outlet –

DOC Inlet >

365˚C

Torque

Derate

Torque

Derate

Torque Derate, Vehicle

Speed Limit, and Engine

Shutdown

DPF Outlet –

DOC Outlet >

540˚C

Torque

Derate

Torque

Derate

Torque Derate, Vehicle

Speed Limit, and Engine

Shutdown

DOC Outlet >

800˚C

Torque

Derate

Torque

Derate

Torque Derate, Vehicle

Speed Limit, and Engine

Shutdown

DPF Outlet >

687˚C OR

DPF Outlet –

DOC Outlet >

300˚C

Torque

Derate

Torque

Derate

Torque Derate, Vehicle

Speed Limit, and Engine

Shutdown

SCR Outlet >

650˚C

Torque

Derate

Torque

Derate

Torque Derate, Vehicle

Speed Limit, and Engine

Shutdown
