The dispensing plates peel the label from the base
paper and apply it to the products.
The PU drive roller pulls the base paper to apply the
labels. The aluminum knurled roller must be closed
and locked in place with the PU roller in order to
squeeze the base paper and pull effectively. See below.
OPENED
CLOSED
BASE PAPER COLLECTOR
Remove the collector cap on the base paper collector and wind the base paper through the collector
rods. Then reinstall the collector cap to secure the collector rods and ensure proper pickup tension.
