Pack Leader ELF-50 - Control Box Parts List

|
27
CONTROL BOX FRAME PARTS LIST
NO.
DESCRIPTION
PARTS NO.
QTY.
1
Emergency Cutoff Switch
C-1403
1
2
Main Switch
C-1400
1
3
Panel Sticker
2Y1F-ELFCS0010
1
4
Front Panel
CS1-ELF-002
1
5
Push Button Assembly
CS1-ELF-004
1
6
Push Button
2YPCB-SS30326A
1
7
LCD Display
C-1040
1
8
PC Board
2YPCB-SS30105B
1
9
IC Chip A
2YIC-89S5124AT
1
10
IC Chip B
2YIC-89C51
1
11
Top Cover
CS1-ELF-003
1
12
Exhaust Fan
2Y2G-KD2406PTB1
1
13
Base Cover
CS1-ELF-001B
1
14
Power Supply Fabrication
2YE2-RD35B
1
15
2 Phase Stepper Driver DA2D20B
2YF2-DA2D20B
1
16
EMI Filter
2YXQF-20A250VAC
1
17
Fuse 10A
C-1708
1
18
Seat Of Fuse
E-0160
1
19
Copper Ingot
C-1800
1
20
Terminals 4 Pin
C-1508
1
21
Transformer
2Y1U-2301104C
1
22
Inverter VF002S23A
2Y1Q-VF002S23A
1
