Pack Leader ELF-50 - Control Panel; Control Panel Overview

|
15
CONTROL PANEL
CONTROL PANEL LIST
NO.
DESCRIPTION
FUNCTION
1
Main Power Switch
Cut off or connect to main power supply
2
Emergency Switch
Emergency cutoff of power supply
3
Liquid Crystal Display
Displays the data
4
Length Sett
To set up the label length required
5
Value
To select the numeric value to be entered/on for printer
6
Menu
To exit and scroll the menu
7
Digit
To select the digits to be changed/off for printer
8
Labeling On
To start conveyor and make settings changes
9
Labeling Off
To stop conveyor and make changes on setting
