Pack Leader ELF-50 - Base Paper Collect Assembly

|
32
BASE PAPER COLLECT ASSEMBLY
BASE PAPER COLLECT ASSEMBLY PART LIST
NO.
DESCRIPTION
PARTS NO.
QTY.
1
Paper Collect Plate
LA1-ELF-018
1
2
Paper Collect Base
LA1-ELF-017
1
3
Collector Rods
LA1-ELF-019
3
4
Philips Head Screws
XNMW-M415
3
5
Paper Collect Shaft
LA1-ELF-020
1
6
Washer
XNQC-M8
1
7
Spring Washer
2FWO-M8
1
8
Screw Nut
XAXR-M8S
1
9
Collector Cap
LA1-ELF-039
1
10
Collector Gear
LA1-ELF-041
1
11
S-Ring S15
DCSV-S15
1
12
Socket Set Screw
XN5Z-M45
1
