Pack Leader ELF-50 - Page 31

|
31
APPLICATOR MOTOR ASSEMBLY PART LIST
NO.
DESCRIPTION
PARTS NO.
QTY.
1
Applicator Base Plate
ELF1050501-001
1
2
PU Roller Bearing Seat
LA1-ELF-021
1
3
Bearing 6002NR
5TGH-6002NR
3
4
Pad Of Stepper Motor
LA1-ELF-023
1
5
Motor Gear
LA1-ELF-040
1
6
Spacing Rod
LA1-ELF-022
3
7
Bearing 6901NR
5TGH-6901NR
1
8
Stepper Motor
A21R-DA29902H8
1
9
Double Head Round Keys
RGM-4420
1
10
Socket Set Screw
XN5Z-M45
2
11
Spring Washer-M4
2FWO-M4
3
12
Socket Head Cap Screws
XNJW-M416
3
13
Spring Washer-M6
2FWO-M5
6
14
Socket Head Cap Screws
XNJW-M525
4
15
Socket Head Cap Screws
XNJW-M616
5
16
Spring Washer-M6
2FWO-M6
8
17
Washer-M5
XNQC-M5
2
18
Nut-M5
XAXR-M5
2
19
Back Cover
ELF1050501-002
1
20
Main Rod
ELF1050501-017
1
21
Socket Head Cap Screws
XNJW-M620
4
22
Socket Head Cap Screws
XNJW-M830
2
23
Spacing Block
ELF1050501-032
1
