Pack Leader ELF-50 - Page 60

|
60
CONVEYOR ASSEMBLY PART LIST
NO.
DESCRIPTION
PARTS NO.
QTY.
1
Conveyor Plate
CV1-ELF-001C
1
2
Conveyor Driven Pulley Assembly
See page 63
1
3
Conveyor Driving Pulley Assembly
See page 62
1
4
Conveyor Motor Assembly
See page 61
1
5
Timing Belt 120XL-050
T2Q2-120XL050
1
6
Tension Adjustment Block
CV1-ELF-008
2
7
Guide Rail -1
GR1-ELF-001B
1
8
Spacing Pillar
CV1-ELF-010
4
9
Guide Rail -2
GR1-ELF-002
1
10
Conveyor Belt 150W*2040L
T2EW-150W2040LA
1
11
Guide Rail Fixing Base
CV1-ELF-011
8
12
Bridging Plate
CV1-ELF-012
1
13
Locking Screw Q339
51WR-Q339
4
14
Heater Box Fixed Rod
CV1-ELF-020
2
15
Guide Rail Front & Back Positioned Rod
GR1-PL501-009
4
16
Star Knob
51WR-606025M615
4
17
Guide Rail Front & Back Adjusting Rod
51CX-K-PIN-150
2
18
Guide Rail Front & Back Adjusting Rod
51CX-K-PIN-30
2
19
Guide Rail Up & Down Adjusting Rod
51CX-UD-D12140
4
