Pack Leader ELF-50 - Page 66

|
66
FOOT STAND ASSEMBLY PART LIST
NO.
DESCRIPTION
PARTS NO.
QTY.
1
Stand Connector
FT1-ELF-014C
2
2
Supporter Connecting Base
FT1-ELF-025C
2
3
Supporter Connecting Base (Inner)
FT1-ELF-026C
2
4
Back Stand Connector
FT1-ELF-034C
1
5
Pad
51WR-NS401285
4
6
Conveyor Supporter-Right
FT1-ELF-023E
2
7
Stand Connector-Front Right
FT1-ELF-033
1
8
Conveyor Fixed Supporter(Inner)
FT1-ELF-018D
4
9
Conveyor Fixed Supporter (Outer)
FT1-ELF-017C
4
10
Plug
QVDG-HP13
12
11
Control Box Panel Fixed Plate (Right)
FT1-ELF-021
1
12
Control Box Cover
CS1-ELF-006
1
13
Panel
CS1-ELF-002B
1
14
Control Box Panel Fixed Plate(Left)
FT1-ELF-022
1
15
Stand Connector-Front Left
FT1-ELF-032
1
16
Aluminum Extrusion
FT1-ELF-035
2
17
Conveyor Supporter-Left
FT1-ELF-024E
2
18
Adjustment Fixed Base
FT1-ELF-028C
1
19
Adjustment Fixed Base (Outer)
FT1-ELF-029B
1
20
Adjustment Fixed Base( Inner)
FT1-ELF-030B
1
