PACSystems RX3i - Page 40

User Manual Chapter 3
GFK-2749A Jan 2020
Configuration and Data Transfer 36
Parameter
Function
VAxH Gain
Calibration constant. Value provided on the ACC200
Terminal Assembly label.
Improves the accuracy of the 600V range of channel 1 (VA).
This value can be further adjusted to compensate for
inaccuracies of external Potential Transformers and wiring.
Range: 0h to FFFFh
Default: 4000h
IAx Gain
Calibration constant. Value provided on the ACC200
Terminal Assembly label.
Improves the accuracy of the current measurement of
channel 2 (IA). This value can be further adjusted to
compensate for inaccuracies of external Current
Transformers and wiring.
Range: 0h to FFFFh
Default: 4000h
VBxL Gain
Calibration constant. Value provided on the ACC200
Terminal Assembly label.
Improves the accuracy of the 120V range of channel 3 (VB).
This value can be further adjusted to compensate for
inaccuracies of external Potential Transformers and wiring.
Range: 0h to FFFFh
Default: 4000h
VBxH Gain
Calibration constant. Value provided on the ACC200
Terminal Assembly label.
Improves the accuracy of the 600V range of channel 3 (VB).
This value can be further adjusted to compensate for
inaccuracies of external Potential Transformers and wiring.
Range: 0h to FFFFh
Default: 4000h
IBx Gain
Calibration constant. Value provided on the ACC200
Terminal Assembly label.
Improves the accuracy of the current measurement of
channel 4 (IB). This value can be further adjusted to
compensate for inaccuracies of external Current
Transformers and wiring.
Range: 0h to FFFFh
Default: 4000h
VCxL Gain
Calibration constant. Value provided on the ACC200
Terminal Assembly label.
Improves the accuracy of the 120V range of channel 5 (VC).
This value can be further adjusted to compensate for
inaccuracies of external Potential Transformers and wiring.
Range: 0h to FFFFh
Default: 4000h
