PACSystems RX3i - Configuration for 480 V 4-Wire WYE Synchro;Power Control Connection

User Manual Chapter 3
GFK-2749A Jan 2020
Configuration and Data Transfer 71
%Q Bit
Offset
Function
Value
Comment
7
GRID 1 PTB measurement
1
VB1 measurement is on
8
GRID 1 CTB measurement
1
IB1 measurement is on
9
GRID 1 PTC measurement
1
VC1 measurement is on
10
GRID 1 CTC measurement
1
IC1 measurement is on
11
GRID 1 CTN measurement
1
IN1 measurement is on
12
GRID 1 Waveform Capture
0
Set this to capture a waveform
13
GRID 1 Delta Mode
0
Delta Mode only affects Delta
configurations
14
Reserved
0
Always zero
15
GRID 1 Energy reset
0
Set this to reset Energy value to Zero
16
Relay open
1
Clear this bit (AND set bit 32) to
request synchronizing the Grids
17
GRID 2 Operation
1
Enable grid 1
18
GRID 2 Voltage Selection
0
120VAC range
19
GRID 2 Grid Operational Mode
1
3-phase
20
GRID 2 Connection mode
0
4-wire, Wye power system
21
GRID 2 PTA_CA measurement
1
VA2 measurement is on
22
GRID 2 CTA measurement
1
IA2 measurement is on
23
GRID 2 PTB measurement
1
VB2 measurement is on
24
GRID 2 CTB measurement
1
IB2 measurement is on
25
GRID 2 PTC measurement
1
VC2 measurement is on
26
GRID 2 CTC measurement
1
IC2 measurement is on
27
GRID 2 CTN measurement
1
IN2 measurement is off
28
GRID 2 Waveform Capture
0
Set this to capture a waveform
29
GRID 2 Delta Mode
0
Delta Mode only affects Delta
configurations
30
Reserved
0
Always zero
31
GRID 2 Energy reset
0
Set this to reset Energy value to Zero
32
Relay close
0
Set this bit (AND clear bit 16) to
request synchronizing the Grids
3.3.7 Configuration for 480V 4-Wire WYE Synchro/Power
Control Connection
The following shows a typical hardware configuration for a 3-phase, 4-wire WYE power
paralleling/synchronizing application. The offset and gain values are shown at their default
values. For maximum accuracy, the offset and gain values must be set, based on the
IC694PSM001 module faceplate label and on the IC694ACC200 terminal assembly label
calibration constants. Choose the 600V range and enter 480.0V as the nominal voltage. The
Nominal Voltage is the anticipated Phase-to-Neutral voltage in the WYE configuration.
