PACSystems RX3i - Specifications

User Manual Chapter 1
GFK-2749A Jan 2020
PSM Module Description and Specifications 5
Part Number
Description
IC694CBL200
One replacement 2m (6.56 ft.) interface cable
IC694ACC201
PSM replacement parts:
two finger guards
four thumb screws
one relay connector
two grounding lug nuts
1.7 Specifications
PSM Module Power Requirements
Backplane Power Consumption
400 mA max. at 5 VDC
Total Power Dissipation
2.0 W max.
Isolation from Backplane
1500 VDC
Host Controller Compatibility
RX3i CPUs
For specific versions supported, refer to “Functional
Compatibility” in the Important Product Information
document, GFK-2748.
Maximum number of PSM modules per
RX3i system
No restrictions, as long as the power supply has sufficient
capacity
Sync Relay contacts
Two isolated relay outputs
General purpose:
125 VAC / 125 VDC maximum at 1 amp
Lamp duty:
125 VAC / 125 VDC maximum at 1 amp
Pilot duty:
125 VAC / 125 VDC maximum at 0.35 amp
Switching speeds
20ms
5ms
Turn-on time
Turn-off time
Measurement Specifications
Three voltage inputs per grid
All voltage data is scaled in 0.1 VAC units.
Impedance
>1 MΩ
Range
Low range
High range
45–150 VAC RMS (120VAC nominal)
120–690 VAC RMS (600VAC CAT IV; 690 VAC CAT III)
Frequency
40–70 Hz
Four current inputs per grid
All current data is scaled in 0.001 Amp units.
Impedance
<5 milliohms
Range
0–5 A RMS (5 A nominal)
