PACSystems RX3i - Chapter 4: Diagnostics

User Manual Chapter 3
GFK-2749A Jan 2020
Configuration and Data Transfer 77
%Q Bit
Offset
Function
Value
Comment
4
GRID 1 Connection mode
0
4-wire, Wye power system
5
GRID 1 PTA_CA measurement
1
VA1 measurement is on
6
GRID 1 CTA measurement
1
IA1 measurement is on
7
GRID 1 PTB measurement
1
VB1 measurement is on
8
GRID 1 CTB measurement
1
IB1 measurement is on
9
GRID 1 PTC measurement
1
VC1 measurement is on
10
GRID 1 CTC measurement
1
IC1 measurement is on
11
GRID 1 CTN measurement
1
IN1 measurement is on
12
GRID 1 Waveform Capture
0
Set this to capture a waveform
13
GRID 1 Delta Mode
0
Delta Mode only affects Delta
configurations
14
Reserved
0
Always zero
15
GRID 1 Energy reset
0
Set this to reset Energy value to Zero
16
Relay open
1
Clear this bit (AND set bit 32) to
request synchronizing the Grids
17
GRID 2 Operation
1
Enable grid 1
18
GRID 2 Voltage Selection
1
600VAC range
19
GRID 2 Grid Operational Mode
1
3-phase
20
GRID 2 Connection mode
0
4-wire, Wye power system
21
GRID 2 PTA_CA measurement
1
VA2 measurement is on
22
GRID 2 CTA measurement
1
IA2 measurement is on
23
GRID 2 PTB measurement
1
VB2 measurement is on
24
GRID 2 CTB measurement
1
IB2 measurement is on
25
GRID 2 PTC measurement
1
VC2 measurement is on
26
GRID 2 CTC measurement
1
IC2 measurement is on
27
GRID 2 CTN measurement
1
IN2 measurement is off
28
GRID 2 Waveform Capture
0
Set this to capture a waveform
29
GRID 2 Delta Mode
0
Delta Mode only affects Delta
configurations
30
Reserved
0
Always zero
31
GRID 2 Energy reset
0
Set this to reset Energy value to Zero
32
Relay close
0
Set this bit (AND clear bit 16) to
request synchronizing the Grids
