117
Lowering the Platform
Press the pushbutton (42) and keep it pressed until the plat-
form is adjusted flush to the ground.
After the platform has touched the ground it tilts and adjusts
to the ground.
Lifting the Platform
Press the pushbutton (43) and keep it pressed until the plat-
form has reached the loading position.
Before the platform is lifted it tilts to the horizontal position.
Opening the Platform
Loosen the platform interlock (if present).
Press the pushbutton (41) and keep it pressed until the plat-
form is completely open.
If an optional load safety device is present, the platform is
lowered a small amount and then unfolds to the horizontal
operating position.
Closing the Platform
Press the pushbutton (44) and keep it pressed until the plat-
form is completely closed.
If an optional load safety device is present, the platform
closes approximately to 80° and is lowered a small amount.
Subsequently it moves to the vertical transport position and
is lifted into the load safety device.
Close the platform interlock (if present).
Setting the Platform to its Horizontal Position
In order to obtain a steeper platform tilt angle, press the
pushbutton (44).
In order to obtain a flatter platform tilt angle or let the plat-
form make contact with the ground, press the push-
button (41).
