Column Lifts
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
1 Hydraulic unit with oil tank
2 Hand cable control 1
3 Hand cable control 2
4 Vehicle deck 2
5 Vehicle deck 1
6 Hydraulic hoses
(connected to hydraulic
unit)
7 Guide frame
8 Closing cylinder
9 Roll-stop, towards vehicle
rear
10 Tilt sensor b15 (factory-
set, do not change
position)
11 Warning light
12 Payload center of gravity
13 Link bridge (roll stop,
towards external side)
14 Tilt cylinder
15 Safety railing
16 Slide
17 Top flap
