25
Adjusting the Pressure Switch of the
Hydraulic Stabilizer Feet
If the hydraulic stabilizer feet should lift the vehicle excessively
or should not reach the ground, the pressure switch of the sta-
bilizer can be adjusted.
For this purpose, turn the set screw on the pressure switch.
In order to reduce the contact pressure of the stabilizer feet,
turn the set screw counterclockwise by one turn.
In order to increase the contact pressure of the stabilizer feet,
turn the set screw clockwise by one turn.
After the adjustment, verify the contact pressure by lowering
the stabilizer feet. If the wanted switch-off of the stabilizer is not
achieved, repeat the setting procedure.
Turn set screw
(adjustment range 20 to 50 bars)
- clockwise to
increase pressure
- counterclockwise to
reduce pressure
