110
Bringing Down the Platform
Press the pushbutton (43) and keep it pressed until the
platform is adjusted flush to the ground.
After the platform has touched the ground it tilts and adjusts
to the ground.
Lifting the Platform
Press the pushbutton (42) and keep it pressed until the
platform has reached the loading position.
Before the platform is lifted it tilts to the horizontal position.
Optional Operating Method: Hand Cable
Control with three Pushbuttons
Note: As of May 2019, the hand cable control shown in the illus-
tration is used. Please note: Older models of the hand ca-
ble control have a different pushbutton assignment.
42 Pushbutton: lift
43 Pushbutton: tilt
44 Pushbutton: lower
Betriebsanleitung_Hubladebuehnen_EN.book Seite 110 Donnerstag, 15. August 2019 4:04 16
