Standard Tail Lifts
B
2 Supporting strap on body
(not in scope of delivery)
4 Hydraulic unit
5 Underrun bumper
9 Railing
12 Payload center of
gravity
14 Platform
17 Torsion frame
18 Lift cylinder
22 Hand cable control
2
4
5
9
17
18
22
14
12
