124
Special Operating Elements for Hydraulic Stabilizer
Feet
54 Toggle switch
Extending the Hydraulic Stabilizer Feet
Push down the toggle switch (54) until the stabilizer feet are
extended almost to the ground.
Retracting the Hydraulic Stabilizer Feet
Push up the toggle switch (54) until the stabilizer feet are
completely retracted.
54
DANGER!
Risk of accidents and injury!
If the instructions in chapter “General Operation” are not ob-
served during operation of the tail lift, personal injuries and
material damage can occur.
Before operating the tail lift, read chapter “General Opera-
tion” from p. 26.
Betriebsanleitung_Hubladebuehnen_EN.book Seite 124 Donnerstag, 15. August 2019 4:04 16
