ld not try to eliminate the faults yourself, but by contractor repair shops and with the aid
of the following tables. The list of repair shops shows you the nearest repair shop and pro-
vides further contact information.
Troubleshooting Tables
WARNING!
Risk of burns in case of short-circuits!
Serious burns can occur in case of a short-circuit of the high-
power batteries.
Before starting any work at the electric system, discon-
nect the battery main switch or disconnect the negative
lead from the battery.
Before switching on
Fault Possible cause Remedy
Optical indication in driver's
cab flashes rapidly
Tilt sensor b15 defective Replace tilt sensor b15
Switching on
(LED on PC board flashes with the same rate as the turn signal)
Fault Possible cause Remedy
Optical indication in driver's
cab flashes furiously
Lift arms switch b13 defec-
tive (short-circuit)
Replace lift arms switch b13
Tilt sensor b15 guide rod de-
fective
Replace tilt sensor b15
LED on PC board does not
flash
ON/OFF switch in driver's
cab defective
Check connections 2 and 4
with test lamp
Fuses in unit e1 or e2 have
tripped
Replace fuses
PC board in sealing cover de-
fective
Replace PC board
