45
Opening the Platform
Loosen the platform interlock (if present).
Turn the rotary switches (28) and (29) simultaneously
downward and hold them down until the platform has
reached the horizontal operating position.
If an optional load safety device is present, the platform is
lowered a small amount and then unfolds to the horizontal
operating position.
Lowering the Platform
Turn the rotary switches (27) and (29) simultaneously
downward and hold them in this position until the platform
has made contact with the ground.
After the platform has touched the ground it tilts and adjusts
to the ground.
Lifting the Platform
Turn the rotary switches (27) and (29) simultaneously up-
ward and hold them in this position until the platform has
reached the vehicle loading floor height.
The platform tilts to the horizontal or preset position before
it is lifted.
Closing the Platform
Turn the rotary switches (28) and (29) simultaneously up-
ward and hold them in this position until the platform is
closed.
If an optional load safety device is present, the platform
closes approximately to 80° and is lowered a small amount.
Subsequently it moves to the vertical transport position and
is lifted into the load safety device.
Close the platform interlock (if present).
Betriebsanleitung_Hubladebuehnen_EN.book Seite 45 Donnerstag, 15. August 2019 4:04 16
