97
Folding Out the Platform
Loosen the platform interlock (if present).
Press the pushbutton (27) and hold.
Protect your hands with gloves.
Pull the handle with both hands to unfold the folding part of
the platform.
Lifting the Platform
Press the pushbutton (28) and hold it in this position until
the platform has reached the loading position.
The platform tilts to the horizontal or preset position and is
then lifted.
Lowering the Platform
Press the pushbutton (27) and hold it in this position until
the platform is adjusted flush to the ground.
After the platform has touched the ground it tilts and adjusts
to the ground.
Folding In the Platform
Make sure that the platform is in horizontal position touch-
ing the ground.
Protect your hands with gloves.
Unfold the folding part of the platform with both hands from
the operating position onto the stationary part of the plat-
form.
Close the platform interlock (if present).
Swivel the platform up to the roller at the support tube.
Press the pushbutton (28) and hold it in this position until
the platform is folded away under the vehicle.
The platform lifts and is moved under the vehicle.
