ADJUST POSITION OF LIFT
Adjust the height of the lift until the beam is
level with floor.
Column ground clearance for when under-
run bar is to be installed should be
approximately 430mm (maximum 550mm).
If necessary, cut bottom of columns,
ensuring all burrs are removed from inside
faces of column.
Adjust the lift so that it is central to body.
Clamp the lift to the rear frame.
To avoid damage to the plastic runner slide pads, do not weld in area 'A' (800mm
from the bottom of the runner).
