Palfinger V Series User Manual

11
FULLY WELD COLUMNS TO VEHICLE
(For unpainted steel)
Using 5mm fillet welds of 100mm in length,
weld columns to vehicle rear frame. Welds
to be on both sides of each column.
Allow the welds to cool, lower platform to
ground and complete welds.
To avoid damage to the plastic runner slide pads do not weld temporarily in
area 'A'.
