www.pall.com/biopharm 22
9. Adding Powder
P
re-measured powder additions can be added into the mixer using the support mechanism on the
Allegro mixer tote and the 3 in. powder addition port.
1. Powder can be pre-dispensed into an appropriate
powder delivery bag (e.g 1 or 5 kg) and supported
on the optional frame.
4. Connect the powder bag to the 3 in. port on the mixer (A). When connected
the red clip (B) on the powder bag can be removed to dispense the
powder into the uid. Some powder bags have a ush line.
WARNING!
Do not attempt to place hand through the 3 in. powder addition port at
any point during operation. Risk of personal injury.
5. Reconnect 3 in. powder port cap, secure with clamp and switch inflation
to 'ON' to re-inflate the mixer biocontainer.
2. Switch ‘BAG INFLATION’ Switch to the ‘OFF’ Position.
3. Open the 3 in. port on the top of the mixer (A)
and remove the plug (B) from the powder bag.
A
A
B
B
