To determine which servicing fixtures and tools are required for each adjustment, refer to the following table.
No. Parts No. NAME
ADJUSTMENT ITEM
1
2
VFM3010EDS
VFM3110EDS
DV Alignment Tape (Color bar)
DV Alignment Tape (Color bar)
5-2. PG shifter adjustment (SEC.4)
3 VFM3000LS DV Alignment Tape (Linearity) 1-8. LISTA Sensitivity Detection (SEC.3)
1-9. LISTA Linearity Adjustment (SEC.3)
4
5
VVS0026
VVS0027
EVR Adjustment Software 4. ADJUSTMENT PROCEDURE (CAMERA SECTION) (SEC.4)
5. ADJUSTMENT PROCEDURE (VTR SECTION) (SEC.4)
6 VFK1481N LISTA Software 1-8. LISTA Sensitivity Detection (SEC.3)
1-9. LISTA Linearity Adjustment (SEC.3)
7
8
9
10
11
12
VFK1308P
VFK1309A
VFK1763
VFK1982
VJA0941
VFK1317
Measuring Board
EVR Connector Board
Connection Adapter
Extension Cable
DC Cable
30pin Flat Cable
1-8. LISTA Sensitivity Detection (SEC.3)
1-9. LISTA Linearity Adjustment (SEC.3)
1-11. Self-REC/PLAY Envelope Waveform Confirmation (SEC.3)
4. ADJUSTMENT PROCEDURE (CAMERA SECTION) (SEC.4)
5. ADJUSTMENT PROCEDURE (VTR SECTION) (SEC.4)
13 VFK1809 72mm Attachment Ring 4-5. Zoom tracking adjustment (SEC.4)
4-6-2. White balance adjustment (5100K) (SEC.4)
4-6-3. White balance adjustment (4500K) (SEC.4)
4-6-4. White balance adjustment (3600K) (SEC.4)
14
15
VFK1164TAR43
VFK1164TCM01
43mm Attachment Ring
Collimator Set (Infinity Lens)
4-5. Zoom tracking adjustment (SEC.4)
16
17
18
19
VFK1345
VFK1346
VFK1659
VFK1660
CC Filter Holder
Step Down Ring
Step-Up Ring (43mm-49mm)
Step-Up Ring (49mm-62mm)
4-6-2. White balance adjustment (5100K) (SEC.4)
4-6-3. White balance adjustment (4500K) (SEC.4)
4-6-4. White balance adjustment (3600K) (SEC.4)
20 VFK1341 CC Filter (LB40) 4-6-4. White balance adjustment (3600K) (SEC.4)
21 VFK1342 CC Filter (LB80) 4-6-3. White balance adjustment (4500K) (SEC.4)
22 VFK1347 CC Filter (LB120) 4-6-2. White balance adjustment (5100K) (SEC.4)
4-6-3. White balance adjustment (4500K) (SEC.4)
23
24
VFK1884
VFK1888
CC Filter (LBA2)
CC Filter (LBB6)
4-6-2. White balance adjustment (5100K) (SEC.4)
25
26
VFK1885
VFK1886
CC Filter (LBB2)
CC Filter (CC C10)
4-6-4. White balance adjustment (3600K) (SEC.4)
27 VFK1887 CC Filter (CC C20) 4-6-3. White balance adjustment (4500K) (SEC.4)
28 VFK1409A Measuring Board 1-8. LISTA Sensitivity Detection (SEC.3)
1-9. LISTA Linearity Adjustment (SEC.3)
29 VFK1899 Post Driver 1-9. LISTA Linearity Adjustment (SEC.3)
1-10. Tape Path Confirmation (SEC.3)
1-11. Self-REC/PLAY Envelope Waveform Confirmation (SEC.3)
30
31
32
VFK1810
VFK1186
VFK1300
LISTA Measuring Board
LISTA Cable
A/D Converter Board
1-8. LISTA Sensitivity Detection (SEC.3)
1-9. LISTA Linearity Adjustment (SEC.3)
