Panasonic AG-DVX100BP - SECTION 3 MECHANICAL ADJUSTMENT; 1. MECHANICAL ADJUSTMENT AND CONFIRMATION

MECHANICAL ADJUSTMENT
MODEL:
AG-DVX100BP/E/AN,102BEN,DVC180BMC
CONTENTS
1. MECHANICAL ADJUSTMENT AND CONFIRMATION ..........................................................MECH-1
1-1. Name of Tape Transportation.........................................................................................MECH-1
1-2. Tape Path Adjustment Procedure...................................................................................MECH-1
1-3. Adjustment of S1 & T2 Post............................................................................................MECH-2
1-4. Confirmation of EVR Tools .............................................................................................MECH-2
1-5. Connection of LISTA Adjustment System ......................................................................MECH-4
1-6. Boot up the LISTA Software ...........................................................................................MECH-6
1-7. How to Enter the Alignment Tape Data ..........................................................................MECH-7
1-8. LISTA Sensitivity Detection ............................................................................................MECH-8
1-9. LISTA Linearity Adjustment ............................................................................................MECH-9
1-10.Tape Path Confirmation.................................................................................................MECH-11
1-11.Self-REC/PLAY Envelope Waveform Confirmation.......................................................MECH-11
2. MECHANICAL PARTS REPLACEMENT PROCEDURE........................................................MECH-12
2-1. Cleaning Roller Unit........................................................................................................MECH-12
